48*25G port + 8*100G port Layer3 100G Ethernet Switch
Posted on 2025-05-23

With the explosive growth of cloud computing and AI computing demands, 100G switch technology has undergone continuous iteration since its commercial deployment in 2015.


48*25G port + 8*100G port Layer3 100G Ethernet Switch

●Switching Capacity Leap: Increased from 1.2Tbps to mainstream 2.4-3.6Tbps

●Port Density Optimization: 48+ 25G ports with 8+ 100G uplinks becoming industry standard

●Energy Efficiency Innovation: Over 40% power reduction through 16nm chip technology

●Virtualization Enhancement: Deep integration of VXLAN/EVPN protocols with hardware virtualization


C-LIGHT CLS6865-56YC Core Innovations

●Intelligent Traffic Scheduling: 128MB deep buffer enables 400μs micro-burst handling without packet loss

●Virtualized Architecture: M-AG multi-active gateway technology supports seamless VM migration

●Reliability Design:

-Modular power supply (1+1 redundancy) with smart thermal control

-Overvoltage protection for critical components (12KV surge protection)

●Environmental Adaptability: -10℃~55℃ operating range for edge computing deployments


Key Specifications

ParameterSpecification
Switching Capacity2.4Tbps
Port Configuration48*25G SFP+Port + 8*100G QSFP28
Forwarding Rate1780Mpps
Power Efficiency≤88W (Full Load)
Physical Dimension1U (440*390*44mm)


Typical Application Scenarios

●Cloud Data Center Core: Builds non-blocking CLOS fabric with 400G upgrade capability.

●Enterprise Campus Backbone: 128MB buffer aggregates 4K video conferencing traffic.

●Smart Manufacturing: Industrial-grade operation with<1μs synchronization precision.


Evolution Trend: Pre-installed 400G optical interfaces support SD-Hardware architecture for "pre-deployed hardware, on-demand feature activation" deployment model.


If you are interested in the Layer3 100G Ethernet Switch, please contact us sales@c-light.com
